Video wall Kiosk

Ultra Narrow LCD Video Wall Screens
◇ Ultra narrow 1.7 to 5.5mm edge seamless splicing display,
◇ 1920x1080(FHD), 500nits and 700nits, 178 degrees all perspective, split screens display
◇ Used in LCD, LG, SAMSUNG’s second brand, A gauge without spot or black spots.
◇ Wire custom-made,and go trough,layout of the whole knot, easy to maintain,
◇ Support 3 CVBS,YPbPr, Display Port, HDMI,VGA,DVI input,To support the computer centralized control by computer stitching unit parameter adjustment automatic intelligent temperature control system,energy conservation,environmental protection, make splicing unit has higher stability and reliability
◇ Can be divided into play area,quality can be clearly seen

Supper Narrow Bezel Video Wall Screen
The ultra slim 1.7 to 5.5mm edge to edge bezel creates virtually seamless video walls for a more elegant and impactful delivery of your message, Keep the focus on the images. Combining the usage of LED technology and an advance Smart HDMI feature keeps your screens running efficiently at all times making ZHONGXIN Matrix LED the most reliable, cost efficient and eco-friendly solution for all your needs.
2 x 2 x 46 inch (92 inch) , 2 x 2 x 55 inch (110 inch),3 x 3 x 46 inch (138 inch), 3 x 3 x 55 inch (165 inch),4 x 4 x 46 inch (184 inch), 4 x 4 x 55 inch (220 inch)

Ultra Matrix Video Wall Screen
With ZHONGXIN MATRIX Video Wall Screen, this incredibly slim and light weight LED panel, you will create the ultimate video wall with screens that are seamlessly connected and picture perfect. This makes it easy to make a big impact on your audiences.Matrix: 4 input x 4 output, 8 input x 8 output, 16 input x 16 output

Eeasy To Installation & Operation
With content constantly changing, you need a reliable and easy software solution that lets you communicate with remote displays in a cost-effective,time-efficient manner. ZHONGXIN MATRIX offers Multi Display Control solution that lets you control any number of screens through their embedded RJ45 interfaces. Easy and intuitive to use.

High-quality features enable 24/7 operation
Long operating times create ideal ranges with digital signage applications. In control rooms, an around-the-clock representation of security cameras is desirable. With the optionally activatable non-stick-mode, eyevis-displays can thus counteract burn-in effects (Image Sticking) of static contents or the premature aging of the TFT-cells. This is achieved by the integrated pixel-shift-technology, dynamic-pixel-refreshing and the high-quality electronic components. Thus a 24/7 operation is possible and is supported by these technical measures.

Specification

Product Specifications
Model	ZX-VD46	ZX-VD47	ZX-VD49	ZX-VD55
Panel Size	46”	47”	49”	55”
Resolution	1920 x 1080(FHD)	1920 x 1080(FHD)	1920 x 1080(FHD)	1920 x 1080(FHD)
Visual angle L/R	178°/178°	178°/178°	178°/178°	178°/178°
Brightness	450 cd/m²	500 cd/m²	500 cd/m²	500 cd/m²
Display Area(H)X(V)	1018.08×572.67mm	1039.68x584.82mm	1077.6*607.8mm	1209.6×680.4mm
Contrast ratio	4000:1	4000:1	4000:1	4000:1
Color	16.7M	16.7M	16.7M	16.7M
Operating Voltage	AC 100V-240V, 50/60 Hz	AC 100V-240V, 50/60 Hz	AC 100V-240V, 50/60 Hz	AC 100V-240V, 50/60 Hz
Power Consumption	240W	240W	240W	240W
Installation Type	Wall Mounted	Wall Mounted	Wall Mounted	Wall Mounted
Safty protection	Safty Lock Design	Safty Lock Design	Safty Lock Design	Safty Lock Design
Working Temperature	0℃-40℃	0℃-40℃	0℃-40℃	0℃-40℃
Storage Temperature	-20℃-60℃	-20℃-60℃	-20℃-60℃	-20℃-60℃
Video Wall Controller(Built-in each Screen)
Digital signal input	HDMI×1, 1920x1080@60Hzbackward compatible		Composite Video Output	CVBS(BNC)x1
Computer signal input	VGA(DB-15)×1, 1920x1080@60Hzbackward compatible		RJ45	4
Digital signal input	DVI(DVI-I)×1, 1080P(1920×1080) backward compatible		USB	1(optional)
Composite Video Input/(AV)	CVBS(BNC)x1		RS232	1
